ASROCK H610M-H2/M.2 14th, 13th and 12th Gen mATX DDR5 Motherboard
Availability : In Stock
SKU: PC-ASROCK-H610M-H2-M2-MOTHERBOARD
Brand: ASRock
৳ 9,100
৳ 9,600
You save ৳ 500
(5% OFF)
Only left in this option This option is out of stock
Quantity:
1
Inside Dhaka: ৳ 80
Outside Dhaka: ৳ 150
100% original product
Need Help? Contact Us:
No description available for this product.
| Supported CPU | Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700), Supports Intel® Hybrid Technology, Supports Intel® Turbo Boost Max 3.0 Technology |
|---|---|
| Chipset | Intel H610 |
| BIOS | 128Mb AMI UEFI Legal BIOS with GUI support |
| Form Factor | Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm |
| Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| PCI | CPU: 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode, Chipset:1 x PCIe 3.0 x1 Slot (PCIE2) |
| M.2 Socket | 1 x Ultra M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode, 4 x SATA3 6.0 Gb/s Connectors |
| Type | Dual Channel DDR5 Memory Technology |
| Slots | 2 x DDR5 DIMM Slots |
| Supported Memory | 13th Gen Intel Core Processors support DDR5 non-ECC, un-buffered memory up to 5600, 12th Gen Intel Core Processors support DDR5 non-ECC, un-buffered memory up to 4800, Supports Intel Extreme Memory Profile (XMP) 3.0 |
| Maximum Memory | 96GB |
| Graphics | Intel Xe Graphics Architecture (Gen 12), 2 x HDMI 2.1 TMDS Compatible, support HDCP 2.3 and max. resolution up to 4K 60Hz |
| HDMI | 2x HDMI Port 2.1 |
| USB (s) | 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front), 6 x USB 2.0 (4 Rear, 2 Front) |
| LAN Port (s) | Gigabit LAN 10/100/1000 Mb/s, Realtek 8111H |
| Supported Storage | Chipset:, 1 x Ultra M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode, 4 x SATA3 6.0 Gb/s Connectors |
| Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| Internal I/O Ports | 1 x SPI TPM Header, 1 x Chassis Intrusion and Speaker Header, 1 x CPU Fan Connector (4-pin)*, 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control), 1 x 24-pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 1 x Front Panel Audio |
